46 Planar PD520 Owner’s Operating Manual
PREL
IMINA
RY
Example: [S4A0006 selects RGB
[ +4A Select “next” Main AV input
[ S4E 000# Aspect ratio selection
0 = 4:3 (Standard)
1 = Native
2 = Letterbox
3 = 16:9
Example: [S4E0002 selects Letterbox
[ S4G 000# PIP Input selection
1 = Input1
2 = Input2
3 = Input3
4 = Input4
6 = RGB
8 = HDMI1
9 = HDMI2
Example: [S4G0003 selects PIP Input3
[ +4G Select “next” PIP AV input
[ SAB 000# Power on/off control
0 = standby, 1 = on
Example: [SAB0001 turns unit on
[ SDA 000# Set PIP mode
0 = OFF
1 = PIP
2 = PBP
Example: [SDA0002 selects PBP
[ SDB 000# Set PIP size
0 = small
1 = medium
2 = large
3 = very large
Example: [SDB0001 selects medium PIP size
[ SDE 000# Set PIP aspect ratio
0 = 4:3
1 = 16:9
Example: [SDE0001 selects 16:9 aspect ratio PIP window
[ SDF 000# Set PIP window position
0 = Top/Left
1 = Top/Right
2 = Bottom/Left
3 = Bottom/Right
Example: [SDF0001 positions PIP window in upper-right corner of display area
Table 6-1. Serial Commands
Command Description
