Panasonic HD1700pe - Manual (Page 99)

99
717* 1
CH5 IN SEL
For selecting the CH5 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
(CH1 input)
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.723 (D IN SEL 56).
718* 1
CH6 IN SEL
For selecting the CH6 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
(CH2 input)
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.723 (D IN SEL 56).
719* 1
CH7 IN SEL
For selecting the CH7 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
(CH3 input)
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.724 (D IN SEL 78).
720* 1
CH8 IN SEL
For selecting the CH8 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
(CH4 input)
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.724 (D IN SEL 78).
Setup menus
The underlining (__) denotes the factory setting mode.
(continued)
No./Item Description of setting No./Item Description of setting
721* 1
D IN SEL12
For selecting the CH1 and CH2 digital input
signals.
0000 AES: AES/EBU
0001 SDI: Serial
722* 1
D IN SEL34
For selecting the CH3 and CH4 digital input
signals.
0000 AES: AES/EBU
0001 SDI: Serial
723* 1
D IN SEL56
For selecting the CH5 and CH6 digital input
signals.
0000 AES: AES/EBU
0001 SDI: Serial
724* 1
D IN SEL78
For selecting the CH7 and CH8 digital input
signals.
0000 AES: AES/EBU
0001 SDI: Serial
725* 1
REC CH1
For selecting the input signals to be recorded
on the audio CH1 track.
0000 CH1: Audio input CH1 signals
0001 CH2: Audio input CH2 signals
0002 CH3: Audio input CH3 signals
0003 CH4: Audio input CH4 signals
0004 CH1+2: Audio input CH1 and CH2
mixed signals
0005 CH3+4: Audio input CH3 and CH4
mixed signals
726* 1
REC CH2
For selecting the input signals to be recorded
on the audio CH2 track.
0000 CH1: Audio input CH1 signals
0001 CH2: Audio input CH2 signals
0002 CH3: Audio input CH3 signals
0003 CH4: Audio input CH4 signals
0004 CH1+2: Audio input CH1 and CH2
mixed signals
0005 CH3+4: Audio input CH3 and CH4
mixed signals
727* 1
REC CH3
For selecting the input signals to be recorded
on the audio CH3 track.
0000 CH1: Audio input CH1 signals
0001 CH2: Audio input CH2 signals
0002 CH3: Audio input CH3 signals
0003 CH4: Audio input CH4 signals
0004 CH1+2: Audio input CH1 and CH2
mixed signals
0005 CH3+4: Audio input CH3 and CH4
mixed signals
728* 1
REC CH4
For selecting the input signals to be recorded
on the audio CH4 track.
0000 CH1: Audio input CH1 signals
0001 CH2: Audio input CH2 signals
0002 CH3: Audio input CH3 signals
0003 CH4: Audio input CH4 signals
0004 CH1+2: Audio input CH1 and CH2
mixed signals
0005 CH3+4: Audio input CH3 and CH4
mixed signals
729* 1
REC CH5
For selecting the input signals to be recorded
on the audio CH5 track.
0000 CH5: Audio input CH5 signals
0001 CH6: Audio input CH6 signals
0002 CH7: Audio input CH7 signals
0003 CH8: Audio input CH8 signals
0004 CH5+6: Audio input CH5 and CH6
mixed signals
0005 CH7+8: Audio input CH7 and CH8
mixed signals
*1: This item is not displayed when the 23/24 Hz or 25 Hz (HD or
SD) mode has been selected as the system menu item No.25
(SYSTEM FREQ) setting.
