96
Setup menus
The underlining (__) denotes the factory setting mode.
*DW: With SD output (SD tape playback or down-converted
output)
(continued)
No./Item Description of setting No./Item Description of setting
663
C LEVEL
For adjusting the chroma level of the HD SDI
output, SD SDI output and VIDEO output.
(j
j¶ ¶ to 0 dB to i i 3 dB)
0000 0.0%
: :
1000 100.0%
: :
1413 141.3%
660
Pr LVL
(SD)*
DW
For adjusting the PR level of the SD SDI
output and VIDEO output.
(j
j¶ ¶ to 0 dB to i i 3 dB)
0000 0.0%
: :
1000 100.0%
: :
1413 141.3%
661
BK LVL
(SD)*
DW
For adjusting the black level of the SD SDI
output and VIDEO output.
50 j j 10.0%
: :
150 0.0%
: :
250 i 10.0%
This setting takes effect when
“CMPST” has been selected as the
setup menu item No.650 setting.
This setting takes effect when
“CMPNT” has been selected as the
setup menu item No.650 setting.
This setting takes effect when
“CMPNT” has been selected as the
setup menu item No.650 setting.
662
V LEVEL
For adjusting the video level of the HD SDI
output, SD SDI output and VIDEO output.
(j
j¶ ¶ to 0 dB to i i 6 dB)
0000 0.0%
: :
1000 100.0%
: :
2000 200.0%
This setting takes effect when
“CMPST” has been selected as the
setup menu item No.650 setting.
659
Pb LVL
(SD)*
DW
For adjusting the PB level of the SD SDI
output and VIDEO output.
(j
j¶ ¶ to 0 dB to i i 3 dB)
0000 0.0%
: :
1000 100.0%
: :
1413 141.3%
This setting takes effect when
“CMPNT” has been selected as the
setup menu item No.650 setting.
670
BRIGHT
For adjusting the brightness of the LCD
monitor on the front panel.
0 j 127
: :
127 0
: :
254 127
671
R-BRIGHT
For adjusting the brightness (red) of the LCD
monitor on the front panel.
0 j 127
: :
127 0
: :
254 127
672
B-BRIGHT
For adjusting the brightness (blue) of the LCD
monitor on the front panel.
0 j 127
: :
127 0
: :
254 127
673
CONTRAST
For adjusting the contrast of the LCD monitor
on the front panel.
0 j 127
: :
127 0
: :
254 127
674
R-CONTRAST
For adjusting the contrast (red) of the LCD
monitor on the front panel.
0 j 127
: :
127 0
: :
254 127
665
SETUP LVL
(BK LVL*)
For adjusting the setup (black*) level of the
HD SDI output, SD SDI output and VIDEO
output.
(j10% to i10%)
50 j 10.0%
: :
150 0.0%
: :
250 i 10.0%
This setting takes effect when
“CMPST” has been selected as the
setup menu item No.650 setting.
658
Y LVL (SD)* DW
For adjusting the Y level of the SD SDI output
and VIDEO output.
(j
j¶ ¶ to 0 dB to i i 3 dB)
0000 0.0%
: :
1000 100.0%
: :
1413 141.3%
This setting takes effect when
“CMPNT” has been selected as the
setup menu item No.650 setting.
664
HUE
(C PHASE*)
For adjusting the chroma phase of the HD SDI
output, SD SDI output and VIDEO output.
(Approx. j30xx to i 30xx)
0000 j 31.0
: :
0062 0.0
: :
0124 31.0
If 0 (50) or 3 [25 (HD)] or 4 [25 (SD)] has been selected
as the system menu item No.25 (SYSTEM FREQ)
setting:
• The HD SDI output cannot be adjusted.
• The SD SDI output and video output can be adjusted
only when an SD format tape is being created .
This setting takes effect when
“CMPST” has been selected as the
setup menu item No.650 setting.
* This is the name of the menu item for AJ-HD1700E.
