Panasonic HD1700pe - Manual (Page 98)

98
Setup menus
The underlining (__) denotes the factory setting mode.
No./Item Description of setting No./Item Description of setting
700* 1
CH1 IN LV
For selecting the audio input (CH1) reference
level.
0000 4dB
0001 0dB
0002 j 20dB
701* 1
CH2 IN LV
For selecting the audio input (CH2) reference
level.
0000 4dB
0001 0dB
0002 j 20dB
702* 1
CH3 IN LV
For selecting the audio input (CH3) reference
level.
0000 4dB
0001 0dB
0002 j 20dB
703* 1
CH4 IN LV
For selecting the audio input (CH4) reference
level.
0000 4dB
0001 0dB
0002 j 20dB
704* 1
CUE IN LV
For selecting the CUE input reference level.
0000 4dB
0001 0dB
0002 j 20dB
0003 j 60dB
705
CH1 OUT LV
For selecting the audio output (CH1)
reference level.
0000 4dB
0001 0dB
0002 j 20dB
706
CH2 OUT LV
For selecting the audio output (CH2)
reference level.
0000 4dB
0001 0dB
0002 j 20dB
707
CH3 OUT LV
For selecting the audio output (CH3)
reference level.
0000 4dB
0001 0dB
0002 j 20dB
708
CH4 OUT LV
For selecting the audio output (CH4)
reference level.
0000 4dB
0001 0dB
0002 j 20dB
711
MONIR OUT
LV
For selecting the audio monitor output (Rch)
reference level.
0000 4dB
0001 0dB
0002 j 20dB
712
MONI OUT
For selecting the audio monitor output UNITY
or VARIABLE level.
0000 UNITY: The signals are output at a
fixed level.
0001 VAR: The signal output is coupled
with the headphones volume
control.
713* 1
CH1 IN SEL
For selecting the CH1 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.721 (D IN SEL 12).
714* 1
CH2 IN SEL
For selecting the CH2 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.721 (D IN SEL 12).
715* 1
CH3 IN SEL
For selecting the CH3 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.722 (D IN SEL 34).
716* 1
CH4 IN SEL
For selecting the CH4 input signal.
0000 INT SG: The internal signal is selected.
0001 DIGI: Digital input signals are
selected.
0002 ANA: Analog input signals are
selected.
When DIGI has been selected, whether serial or AES is
selected for the input is determined by the setting
selected for setup menu item No.722 (D IN SEL 34).
*1: This item is not displayed when the 23/24 Hz or 25 Hz (HD or
SD) mode has been selected as the system menu item No.25
(SYSTEM FREQ) setting.
709
CUE OUT LV
For selecting the CUE output reference level.
0000 4dB
0001 0dB
0002 j 20dB
710
MONIL OUT
LV
For selecting the audio monitor output (Lch)
reference level.
0000 4dB
0001 0dB
0002 j 20dB
