Table 3-2-1 I/O Port Control Registers (2/2)

Chapter 3 Port Functions

42

Port Control Registers

Name

Address

R/W

Function

P6DIR

P7DIR

P8DIR

P1OMD

PAIMD

P0PLU

P1PLU

P2PLU

P6PLU

P7PLUD

P8PLU

PAPLUD

FLOAT1

X'03F36'

X'03F37'

X'03F38'

X'03F39'

X'03F3A'

X'03F40'

X'03F41'

X'03F42'

X'03F46'

X'03F47'

X'03F48'

X'03F4A'

X'03F4B'

Port 6 direction control register

Port 7 direction control register

Port 8 direction control register

Port 1 output mode register

Port A input mode register

Port 0 pull-up control register

Port 1 pull-up control register

Port 2 pull-up control register

Port 6 pull-up control register

Port 7 pull-up/pull-down control register

Port 8 pull-up control register

Port A pull-up/pull-down control register

Pin control register 1

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W

R/W
