A---7 Powerware 9315 Parallel Redundant System I & O
164202013 Rev. D 041599
Table A--3. Tie Cabinet Power Inputs and Termination Requirements (cont.)
Internal
Hex Size
(In.)
Tightening
Torque
(lb-in)
Size of
Pressure
Termination
(CU wire) Function
Terminal
Point in
Tie
Cabinet
Breakers
MOB 1
and 2
(Amps)
Minimum
Conductor
Size
UPS
Output
NP
Voltage
UPS
Model
150 600 3/0 AWG 200 E9, E10,
E11
Phase A,
B, C
#8-350 kcmil #8-#4, (150)
#3-#1, (200)
#1/0-350
kcmil, (250)
5/16
150 480 4/0 AWG 225 E9, E10,
E11
Phase A,
B, C
#8-350 kcmil #8-#4, (150)
#3-#1, (200)
#1/0-350
kcmil, (250)
5/16
150 400 350 kcmil 300 E9, E10,
E11
Phase A,
B, C
(2) #2/0-400
kcmil or
(1) #6-600
kcmil
#2-600 kcmil,
(375)
#8-#3, (275)
3/8
150 208 (2) 350
kcmil
600 E9, E10,
E11
Phase A,
B, C
(2) #2/0-400
kcmil or
(1) #6-600
kcmil
#2-600 kcmil,
(375)
#8-#3, (275)
3/8
160 600 3/0 AWG 200 E9, E10,
E11
Phase A,
B, C
#8-350 kcmil #8-#4, (150)
#3-#1, (200)
#1/0-350
kcmil, (250)
5/16
160 480 250 kcmil 250 E9, E10,
E11
Phase A,
B, C
#8-350 kcmil #8-#4, (150)
#3-#1, (200)
#1/0-350
kcmil, (250)
5/16
160 400 350 kcmil 300 E9, E10,
E11
Phase A,
B, C
(2) #2/0-400
kcmil or
(1) #6-600
kcmil
#2-600 kcmil,
(375)
#8-#3, (275)
3/8
160 208 (2) 350
kcmil
600 E9, E10,
E11
Phase A,
B, C
(2) #2/0-400
kcmil or
(1) #6-600
kcmil
#2-600 kcmil,
(375)
#8-#3, (275)
3/8
225 208 (2) 300
kcmil
800 E9, E10,
E11
Phase A,
B, C
(3) #3/0-500
kcmil
#3/0-500 kcmil
(375)
3/8
225 480 (2) #4/0 350 E9, E10,
E11
Phase A,
B, C
(2) #2/0-400
kcmil or
(1) #6-600
kcmil
#2-600 kcmil,
(375)
#8-#3, (275)
3/8
300 480 (2) 250
kcmil
450 E9, E10,
E11
Phase A,
B, C
(2) #2/0-400
kcmil or
(1) #6-600
kcmil
#2-600 kcmil,
(375)
#8-#3, (275)
3/8
continued
