Powerware 9315 Parallel Redundant System I & O
164202013 Rev. D 041599
3. Set the pallet on a firm, level surface, allowing a minimum clearance of
4.6m (15 ft) on each side for removing the cabinet from the pallet.
4. Cut the steel bands around the cabinet.
5. Remove the protective cardboard covering from the cabinet, cutting where
indicated, using a knife blade no longer than 25 mm (1 in.).
NOTE: Do not discard the packaging material yet. Instructions for unloading the
cabinet from the pallet are printed on the cardboard, and you will need to
refer to them.
6. Remove the plastic bag and foam packing material, and discard or recycle
them in a responsible manner.
Unloading the Parallel Cabinet From the Pallet
The parallel cabinet consists of four supports secured to foam cushions. The foam
cushions act as shock absorbers for the cabinet during shipment.
WARNING:
Cabinet is extremely heavy. If unloading instructions are not closely
followed, the cabinet may tip and cause serious injury.
Turning the jacking bolts unevenly may cause the cabinet to become
unbalanced. To prevent tipping, raise and lower the jacking bolts
evenly. The cabinet should only be raised approximately 3 mm (
1/8 in.)
above the floor (just enough to remove foam cushions).
1. Remove the doors. Remove the retaining screw located inside each door at
the bottom hinge pivot point, then lift the door off. Save the retaining screws
for reinstallation of the doors.
2. Locate the field kit (packed inside of the cabinet or communication panel).
Locate the four ½-in. jacking bolts and install them in the threaded holes in the
front and rear supports. Place a floor protector underneath each jacking bolt,
and screw the bolts down against them. The floor protectors will save the floor
from being marred by the jacking bolts.
3. Loosen, but do not remove the hardware holding the foam cushions to the
front and rear supports (labeled “1” in Figure 4).
4. Turn each jacking bolt consecutively, two full turns, until the foam cushions
clear the floor by approximately 3 mm ( 1/8 in.).
5. After the foam cushions clear the floor, remove the hardware loosened in
step 3. Pull the foam cushions out from under the cabinet, and discard or
recycle them in a responsible manner.
