Panasonic AV-HS400AN - Manual (Page 20)

20
2. System
2-2. Connections
 Connections when implementing gen-lock
(frame synchronizer OFF)
 When the unit is to be installed and when the connections are to be performed, be absolutely
sure to ask your dealer to be responsible for carrying out the work that needs to be done.
 Use a 3-point power outlet as the power source in order to earth the unit securely.
POWER
1
REF
GPI
SLOT2
2
SLOT
4
2
3 4 SLOT1
1
SLOT2 8
～ IN
SDI INPUTS TALLY
6
6
INPUTS
SIGNAL
SDI OUTPUTS
GND IN OUT
3
IN OUT
2
IN OUT
1
IN OUT
OUTPUTS
1
5 7
SLOT OFF
2
SLOT1 5
SLOT SLOT
PGM RS-422 LAN
ON
Power cord
(AC 100 V to 120 V, 50/60 Hz)
VTR
HD SDI
HD SDI monitor
Multi-Format Live Switcher
AV-HS400AN
HD SDI
HD camera HD SDI
HD camera
HD SDI
HD camera
HD SDI
Sync Generator
HD SDI
HD SDI monitor
HD SDI
HD SDI monitor
