4.6.4 Static MAC Address
This section provides Static MAC Address function from Layer 3 Managed Switch; this function provides Static MAC Ad-
dress and view the MAC Address Table. The Static MAC Address screen in
Figure 4-52 appears and Table 4-19
descriptions the Static MAC Address Configuration Web page objects.
Figure 4-52 Static MAC Address Configuration Web Page screen
Table 4-19 Descriptions of Static MAC Address Web Page screen Objects
Object Description
MAC Address Allow input specific MAC Address for MAC Address binding.
Interface Allow choose one specific port for MAC Address binding.
VID (1-4094) Allow input the VID according to per port belong to which VLAN group..
Add Add MAC Address items to MAC Address table.
Delete Click this button to delete existence MAC Address table list items.
