Specifications
Model Digital camera FinePix E900
Effective pixels 9.0 million pixels
CCD 1/1.6-inch Super CCD HR
Storage media xD-Picture Card (16/32/64/128/256/512 MB/1 GB)
File format Still image: DCF-compliant
Compressed: Exif ver.2.2 JPEG, DPOF-compatible
Uncompressed: CCD-RAW (RAF)
✽ Design rule for Camera File System compliant DPOF compatible
Movie: AVI format, Motion JPEG
Audio: WAVE format, Monaural sound
File size See the table on P.127.
Number of recorded pixels Still image: 3488 × 2616 pixels/3696 × 2464 pixels/2592 × 1944 pixels/
2048 × 1536 pixels/1600 × 1200 pixels/640 × 480 pixels
(⁄/„/÷/3/2/`)
Lens Fujinon 4 × optical zoom lens
F2.8-F5.6
Focal length f=7.2 mm-28.8 mm
(Equivalent to approx. 32 mm-128 mm on a 35 mm camera)
Digital zoom Approx. 7.6 Ч (4Ч optical zoom lens is used together: Max. zoom scale: 30.4×)
Aperture (Wide-angle) F2.8 to F8 10 steps in 1/3 EV increments Manual/Auto selectable
Focal range Normal: approx. 60 cm (2.0ft.) to infinity
Macro: approx. 7.5 cm (3.0 in.) to 80 cm (2.6 ft.) (wide-angle)
Sensitivity AUTO/Equivalent to ISO 80/100/200/400/800
Photometry TTL 256-zones metering Multi, Spot, Average
Exposure control Program AE (B, À, U, ., /, N), Shutter-priority AE, Aperture-priority AE,
Manual exposure
Scene position À (Natural light), U (Portrait), . (Sport), / (Night)
Exposure compensation –2 EV to +2 EV in 1/3 EV-step increments (N, M, <)
Shutter speed B, À, U, ., N: 1/4 sec. to 1/2000 sec.
/, M: 3 sec. to 1/1000 sec.
<: 1/4 sec. to 1/1000 sec. >: 15 sec. to 1/2000 sec.
Continuous shooting Top 4-frame: Number of recorded frames: up to 4 frames
(Max. 1.5 frames/sec.)
Final 4-frame: Number of recorded frames:
last 4 frames before releasing the shutter button
(Max. 1.5 frames/sec.)
Long-period continuous shooting mode:
Number of recorded frames: up to 40 frames
(Max. 0.6 frames/sec.)
Auto bracketing ± 1/3 EV, ± 2/3 EV, ± 1 EV
Focus Mode: Single AF, Continuous AF, Manual focus
AF system: TTL contrast-type
AF frame selection: AF (CENTER), AF (MULTI), AF (AREA)
White balance Automatic scene recognition/Preset (Fine, Shade, Fluorescent (Daylight),
Fluorescent (Warm White), Fluorescent (Cool White), Incandescent, Custom)
Self-timer Approx. 10 sec./2 sec.
Flash type Auto flash
Effective range (û: AUTO): Wide-angle: approx. 30 cm-3.7 m (1.0 ft.-12.1 ft.)
Telephoto: approx. 60 cm-1.9 m (2.0 ft.-6.2 ft.)
Flash mode Auto, Red-Eye Reduction, Forced Flash, Suppressed Flash, Slow Synchro,
Red-Eye Reduction + Slow Synchro
Viewfinder Real image optical Approx. 77% coverage
LCD monitor 2.0 inches, Aspect ratio: 4:3; approx. 115,000 pixels Amorphous silicon TFT,
Approx. 100% coverage
Movie 640 × 480 pixels/320 × 240 pixels (%/$)
(30 frames per second with monaural sound)
A series of continuous image can be recorded up to available recording time per
xD-Picture Card. Zoom cannot be used during movie recording.
Photography functions Best framing, Post shot assist window, Frame No. memory
Playback functions Trimming, Image rotate, Automatic playback, Multi-frame playback, Sorting by
date, Voice memo, Highlight warning
System
Power Supply and Others
Power supply Use one of the following:
i 2
× AA-size Ni-MH (nickel-metal hydride) batteries
i 2 × AA-size alkaline batteries (sold separately)
i AC Power Adapter AC-3VX (sold separately)
Guide to the number of
available frames for battery
operation
Camera dimensions (W/H/D) 102.0 mm × 63.0 mm × 34.4 mm/4.0 in. × 2.5 in. × 1.4 in.
(not including accessories and attachments)
Camera mass (weight) Approx. 200 g/7.1 oz.
(not including accessories, batteries and xD-Picture Card)
Weight for photography Approx. 260 g/9.2 oz. (including batteries and xD-Picture Card)
Operating conditions Temperature: 0°C to +40°C (+32°F to +104°F)
80% humidity or less (no condensation).
According to the CIPA (Camera & Imaging Products Association) standard procedure for
measuring digital still camera battery consumption (extract):
When using Ni-MH batteries, use the batteries supplied with the camera. The storage media
should be xD-Picture Card.
Pictures should be taken at a temperature of 23°C (+73°F), with the LCD monitor turned on, the
optical zoom moved from full wide-angle to full telephoto (or vice-versa) and back again to its
original position every 30 seconds, the flash used at full power every second shot and the
camera turned off and then on again once every 10 shots.
h Note: Because the number of available shots varies depending on the level of charge in Ni-
MH batteries, the figures shown here for the number of available shots using batteries
are not guaranteed.
The number of available shots will also decline at low temperatures.
Ni-MH batteries 2500 mAh Approx. 270 frames
Battery Type With LCD monitor ON
✽ These specifications are subject to change without notice. FUJIFILM shall not be held liable for damages resulting from errors in
this Owner’s Manual.
✽ The LCD monitor on your digital camera is manufactured using advanced high-precision technology. Even so, small bright points
and anomalous colors (particularly around text) may appear on the monitor. These are normal display characteristics and do not
indicate a fault with the monitor. This phenomenon will not appear on the recorded image.
✽ The operation error may be caused in a digital camera by the strong radio interference (i. e. electric fields, static electricity, line
noise, etc.).
✽ Due to the nature of the lens, the edges of images may appear distorted. This is normal.
■ Standard number of available frames/recording time per xD-Picture Card
The number of available frames, recording time or file size varies slightly depending on the subjects photographed. Note also
that the divergence between standard number of frames and the actual number of frames is greater for
xD-Picture Cards with higher capacities.
Input/Output Terminal
A/V OUT (Audio/Visual output) NTSC/PAL-type (with monaural sound)
Digital input/output
USB2.0 High-Speed
DC input socket AC Power Adapter AC-3VX (sold separately)
System
Other functions PictBridge, Exif print, Language (English, Francais, Deutsch, Español, Italiano,
, ), World time (Time difference), FinePix photo mode (p-mode),
Discharging rechargeable batteries
Quality setting ⁄ F ⁄ N
Number of recorded pixels 3488 Ч 2616 3696 Ч 2464 2592 Ч 1944 2048 Ч 1536 1600 Ч 1200 640 Ч 480 – 640 Ч 480
DPC-16 (16 MB) 3
6
28
56
6
13
56
113
DPC-32 (32 MB)
DPC-128 (128 MB)
DPC-256 (256 MB)
113 227 DPC-512/M512 (512 MB)
DPC-M1GB (1 GB) 228 456
„
6
13
56
113
227
456
÷
12
25
102
204
409
819
3
19
40
162
325
651
1305
2
25
50
204
409
818
1639
`
122
247
997
1997
3993
7995
~
%
(30 fps)
0 13 sec.
Image data size 4.5 MB 2.2 MB 2.2 MB 1.2 MB 780 KB 630 KB 130 KB 18.8 MB – –
1 27 sec.
13 28 DPC-64 (64 MB) 28 50 81 101 497 3 55 sec.
6 111 sec.
13 223 sec.
27 7.4 min.
54 14.9 min.
320 × 240
$
(30 fps)
26 sec.
54 sec.
109 sec.
219 sec.
7.3 min.
14.6 min.
29.3 min.
✽
✽ Number of recorded pixel is 4864 × 3648 when displaying images on PC by using FinePixViewer.
