FujiFilm 2600 - Manual

FUJI PHOTO FI LM CO., LTD.
26 - 30, NISHI AZABU 2 - CHOME, MINATO - KU, TOKYO 106-8620, JAPAN
Floppy Disk
Adapter
FD-A2
Image Memory
Card
MG-4S
MG-8S
MG-16S/SW
MG-32S/SW
MG-64S/SW
MG-128SW
O P T I O N A L A C C E S S O R I E S
S Y S T E M C O N F I G U R A T I O N S P E C I F I C A T I O N S
F U N C T I O N S
AC Power
Adapter
AC-3V
Battery Charger
with Battery
BK-NH
• Charged in approx.
2 hours,
• With Euro type or
UK type plug
Rechargeable
Battery
2HR-3UF
• 2 × AA-type Ni-MH
Soft Case
SC-FX26
PC Card Adapter
PC-AD3
Image Memory
Card Reader
SM-R2
FinePix Printer NX-500
SmartMedia™ Card
PC/Mac PC Card Adapter
PC Card Reader
Floppy Disk Adapter
Image Memory Card
Reader
SCSI
PC Card Slot
FDD
USB
USB
DIGITAL CAMERA FinePix 2600 ZOOM
Specifications are subject to change without notice.
Ref. No. EB-111E (SK·00·08·DT·MW) Printed in Japan © 2000 Fuji Photo Film Co., Ltd.
For more information on the full range of Fujifilm digital products, please visit
our Website:
http://home.fujifilm.com
Shutter Button
Flash
Lens Cover
Viewfinder Window
Lens
USB
Interface
DC IN 3V
(Power Input)
Socket
Four-Direction
Button
SmartMedia™
Card Slot
Mode Switch
Power Switch
MENU/OK Button
BACK Button
Viewfinder
DISP Button
LCD Monitor
FinePix 2600 Zoom
CCD sensor 1/2.7-inch square pixel CCD with RGB filter
(Total number of pixels: 2.11 million pixels)
Number of effective 2.0 million pixels
pixels
Image file size
1600 Ч 1200 /1280 Ч 960 / 640 Ч 480 pixels
File format Still image: JPEG (Exif Ver 2.1)
Movie: AVI (Motion JPEG)
* Design rule for Camera File system compliant/DPOF-compatible
Storage media SmartMedia™ Cards (3.3V, 2 – 128MB)
Number of images
Modes Still (1600 × 1200 pixels) Movie
Image quality modes Fine Normal Basic —
MG-4S 4 9 19 23 sec.
MG-8S 10 19 39 47 sec.
MG-16S/SW 20 39 75 94 sec.
MG-32S/SW 41 79 152 191 sec.
MG-64S/SW 82 159 306 385 sec.
MG-128SW 166 319 613 774 sec.
The data sizes and numbers of available shots will vary slightly depending on the type of subject.
Lens Fujinon optical 3✕ zoom lens (Equivalent to 38 – 114mm
on a 35mm camera)
Focal distance Normal: Approx. 0.8m/2.6ft. to infinity
Macro: Approx. 10cm/3,9in. to 0.8m/2.6ft.
Aperture F3.5/F8.7
Viewfinder Real-image optical viewfinder
Exposure control 64-zone TTL metering, Program AE
(Exposure compensation in the Manual mode)
Sensitivity Equivalent to ISO 100
Shutter speeds 1/2 to 1/1,000 sec. (combined with mechanical shutter)
White balance Automatic
Manual [Fine, Shade, Fluorescent light (Daylight),
Fluorescent light (Warm white), Fluorescent light (Cool white),
Incandescent light]
Flash Auto flash using flash control sensor
Flash mode: Auto, Red-eye Reduction, Forced Flash,
Suppressed Flash, Slow Syncro
Effective range: Wide Approx. 0.2 – 3.0m/0.7 – 9.8ft
Telephoto Approx. 0.8 – 3.0m/2.6 – 9.8ft
LCD monitor 1.8-inch D-TFD (72,000 pixels)
Interface USB
Power source 2 AA-size Ni-MH rechargeable batteries
AC power adapter (optional)
(Alkaline batteries are not recommended.)
Dimensions 99.8 (W) × 65.0 (H) × 53.9 (D) mm/3.9 (W) × 2.6 (H) × 2.1 (D) in.
Weight Approx. 200g/ 7.0oz (excluding batteries)
Other Functions
Digital zoom 2.5✕ (640 × 480 mode), 1.25✕ (1280 × 960 mode)
Movie recording 320 × 240 pixels, 10 frames/sec, up to 20 sec, without sound
Playback Single Frame (with max. 5✕ Playback Zoom)/9 Multi-frame
Internet-conferencing Webcam function with “PictureHello”
Others
POWER SAVE mode, Self-timer, DPOF
Accessories 16MB SmartMedia™ card
included 2 AA-size Ni-MH batteries
Ni-MH battery charger
Hand strap
USB cable
CD-ROM
• USB driver
• FinePixViewer
•
DP Editor
• Apple QuickTime 4.0
• VideoImpression
Simulated LCD display image
New
The Perfect Match for
Your Lifestyle!
2.0 M E G A
PIXELS
3
×
ZOOM
Apple is a registered trademark of Apple Computer Inc.
QuickTime is a trademark of Apple Computer Inc.
All other trademarks are the property of their respective holders.
