A
Building Safety. Building Security.
Specifi cations
Ambient temperature -5°C to +50°C
Approval FT 14/147/3/99 (Austria)
VdS G201017
Control Panel Rack
Dimensions W × H × D 478 × 355 (8 height units) × 244 (mm)
height incl. cable channel: approx. 400 (mm)
Part No. 214230
Order name Control Panel Rack/8HU RACK216-1E
Display And Operating Front Panel
Current consumption at 24V typ. 35mA
Connection cable 1.5m
Dimensions W × H × D 478 × 266 (6 height units) × 40 (mm)
Order name Display And Operating Front Panel ABP216-1E
Fire detection control panel module with power unit
Mains voltage 230VAC +10/-15%, 50Hz
Connection power 300VA
Output voltage typ. 27.6VDC
Output peak current typ. 8.4A
Connection of external devices typ. 6A, site-specifi c
Own current consumption at 24V typ. 90mA (without optional componentries)
Dimensions W × H × D 233 Ч 355 Ч 104 (mm)
Part No. 214204
Order name Fire Detection Control Panel Module BCM216-3EPS
Permanent Connection
A variety of peripheral devices can be connected to the
fi re detection control panel BCnet216:
• Fire brigade key safe
• Fire brigade control unit
• Acoustic and optical signaling devices
• External protocol printer
• Remote display and operating panels
• Remote indication unit
• Actuations
• Electronic monitoring system
• Transmitting device for the actuation of pagers via
ESPA protocol
• Modules for remote parameterisation and remote
maintenance via computer newtork, modem or GSM
connection
• Transmitter module for the transmission of messages
via SMS or e-mail
– and much more.
If required, the BCnet216 can be easily expanded to
an extinguishing control panel LCnet216 according to
EN 12094-1. The panel can control up to 127 fl ooding
zones in a maximum of 127 extinguishing systems.
The function of the extinguishing control panel is fully in-
tegrated into the fi re detection control panel BCnet216,
a combined operation is therefore possible.
The LCnet216 is certifi ed to EN 54-2, EN 54-4,
EN 12094-1 and VdS as a pure extinguishing control
panel and as a combined fi re detection and extinguis-
hing control panel.
Optionally, the LCnet216 can be implemented with full
hardware redundancy.
Extinguishing Control System
