Page 63
Installation & Operation Manual
63
Armor water heater control module
NAVIGATION DIAL
(PRESS OR TURN)
RESET KEY
RIGHT SELECT KEY
(SOFT KEY)
LEFT SELECT KEY
(SOFT KEY)
Figure 11-1 Control Panel
Use the control panel (FIG. 11-1) to set temperatures, operating conditions, and monitor water heater operation.
11
Operating information
(continued)
The information on the bottom of the display shows the functions of the two SELECT keys (on either corner), and the
NAVIGATION dial (in the center):
MENU = Left SELECT Key
SETPOINTS = NAVIGATION Dial - Pressing Down
SHDN = Right SELECT Key
