Sidewall direct venting

BIRD

SCREEN

(TYPICAL)

12”

MIN.

12”

MIN.

12”

MIN.

Figure 4-3B Alternate Clearance to Gravity Air Inlets w/
Field Supplied Fittings

FORCED AIR

INLET

VENT / AIR

TERMINATION

7' MIN. ABOVE ANY

PUBLIC WALKWAY

IF LESS

THAN 10’

36"

MIN.

Figure 4-4A Clearance to Forced Air Inlets

IF LESS
THAN 10’

36”

MIN.

FORCED AIR

INLET

BIRD

SCREEN

(TYPICAL)

7’ MIN. ABOVE ANY

PUBLIC WALKWAY

Figure 4-4B Alternate Clearance to Forced Air Inlets w/
Field Supplied Fittings

VENT PIPING

GALVANIZED

THIMBLE

VENT CAP

AIR PIPING

WALL PLATE

VENT PLATE

VENT

AIR

CENTERLINE WIDTH

Figure 4-5A Sidewall Termination Assembly

Prepare wall penetrations

1. Use the factory supplied wall plate as a template to locate

the vent and air intake holes and mounting holes.

Air pipe penetration:
a. Cut a hole for the air pipe. Size the air pipe hole as

close as desired to the air pipe outside diameter.

Vent pipe penetration:
a. Cut a hole for the vent pipe. For either combustible or

noncombustible construction, size the vent pipe hole

with at least a 1/2 inch clearance around the vent pipe

outer

diameter:

• 4½ inch hole for 3 inch vent pipe

• 5½ inch hole for 4 inch vent pipe

• 7½ inch hole (191 mm) hole for 6 inch (152 mm)

vent pipe

Drill 3/16” diameter holes for inserting the plastic anchors
into the wall.

2. Install the vent and air intake piping through the wall into

the vent plate openings. Seal all gaps between the pipes and

wall. Use RTV silicone sealant to seal the air pipe. Use the

cement/primer listed in Table 3A on page 19 to seal the vent

pipe.

3. Mount and secure the vent plate to the wall using stainless

steel screws. Seal around the plate to the wall assuring no

air

gaps.

4. Assemble the vent cap to the vent plate (see FIG. 4-5A).

Insert the stainless steel screws into the vent cap screw hole

openings and securely attach the vent cap to the vent plate.

5. Seal all wall cavities.

26

Model

Air

Vent Centerline

Width

151 - 200

3"

3"

5 5/8"

286 - 601

4"

4"

5 5/8"

701 - 801

4"

6"

7 3/4"

Table 4B Sidewall Vent Centerline Dimensions
