LSIU80ALVD PCI to Ultra2 SCSI Host Adapter IX-1
Index
A
adapter boot order menu 3-5
adapter setup menu
CHS mapping 3-10
host SCSI ID 3-9
parity 3-8
removable media support 3-9
SCAM support 3-8
scan order 3-9
additional adapter configuration menu 3-6
alternate CHS mapping 3-10
B
board characteristics 1-3
bus configurations 2-18
C
chained connection 2-12 , 2-17
change adapter status menu 3-4
command FDISK/MBR 3-10
configuration utility 3-2
connecting the SCSI peripherals 2-7
cylinder head sector mapping 3-10
D
default settings 3-1
detailed installation procedure 2-3
device default settings 3-2
device selection menu 3-11
value changes 3-11
device selection options
disconnect 3-12
exit this menu 3-14
format device 3-13
help 3-13
queue tags 3-13
read/write I/O time-out 3-13
restore default setup 3-14
scan for device at boot time 3-13
scan for SCSI logical units 3-13
sync rate 3-12
verify 3-13
width 3-12
disconnect 3-12
display mode 3-6
duplication of SCSI IDs 2-22
E
edge connector 2-5
electrical characteristics A-2
electromagnetic compliance A-3
erroneous termination 2-18
esc key option 3-7
exit this menu 3-14
exiting the configuration utility
quit option 3-14
external SCSI
bus connections 2-15
connector J3 A-9
device 2-16
device termination 2-20
F
FDISK/MBR command 3-10
features 1-2
format device 3-13
front panel LED 2-14
G
global default settings 3-1
GPIO0_FETCH line A-10
H
hardware connections 2-5
help option 3-7
host SCSI ID 3-9
I
inserting the host adapter 2-4 , 2-6
installation procedure 2-3
check list 2-24
internal SCSI
bus connections 2-10
device connection 2-11
device termination 2-19
ribbon cable 2-10
L
language option 3-6
LED cable 2-14
LED connector 2-14
