Lexmark 3400 Series - Manual (Page 15)

1
2
3
4
5
Use the To
1 Scanner support Hold up the scanner unit.
2 Print cartridge carrier Install, replace, or remove a print cartridge.
3 Scanner unit Access the print cartridge carrier.
4 Power supply Connect the printer to a power source using the power cord.
Note: Insert the power cord into the power supply before you connect
the power cord to the wall outlet.
5 USB port Connect the printer to a computer using a USB cable (sometimes sold
separately).
Note: Insert the USB cable into the USB port before you connect the
USB cable to the computer.
Using the control panel buttons and menus
Using the control panel
Press To
1 Turn the printer on and off.
2
Select Copy , Scan , or Photo Card mode.
(The mode is selected when the light is on.)
3 • Display the menu for the selected mode.
• Select a submenu option that appears on the display.
15
