Lochinvar Sync Condensing Boiler 1.3 - Manual (Page 53)

3
Troubleshooting
(continued)
53
Table 3F (continued from previous page) Troubleshooting Chart - Fault Messages Displayed on Boiler Interface
FAULT DESCRIPTION CORRECTIVE ACTION
Internal Fault
The main control board has detected an
internal fault.
• Replace the main control board.
Writing to
Memos
The main control board has detected an
internal fault.
• Replace the main control board.
CRC Parameters The main control board has detected an
internal fault.
• Replace the main control board.
No Error Stored The main control board has detected an
internal fault. • Press the RESET button on the SMART
TOUCH display panel.
Flue Temp
Shutdown
The stack temperature has exceeded the
set parameters for the boiler.
• Inspect the heat exchanger. Reference page 40 of
this manual for the procedure on how to clean the
flue side of the heat exchanger.
• Inspect the flue sensor and associated wiring.
Measure the resistance of the flue sensor and
compare to Table 3C on page 45 of this manual.
Replace the sensor if necessary.
• Verify that the vent/air intake pipes are properly
installed and that there are no obstructions.
• Replace the main control board.
Delta T
Shutdown
The temperature rise across the heat
exchanger has exceeded the set parameters
for the boiler.
• Verify that the system is full of water and that all air
has been properly purged from the system.
• Verify that the boiler is piped properly into the heating
system. Refer to Section 6 - Hydronic Piping of the
SYNC Installation and Operation Manual
for the proper piping methods for the SYNC boiler.
• Check for voltage to the boiler pump motor on a call
for heat. If voltage is not present, check the wiring
back to the pump relay. Replace the pump relay if
necessary.
• If 120 VAC is present on a call for heat and the boiler
pump is not operating, replace the pump.
• Verify that the boiler pump is set to the proper speed
or that the pump is the proper size. Reference
Section 6 - Hydronic Piping of the SYNC
Boiler Installation and Operation Manual for boiler
pump
specifications.
Outlet Temp
Shutdown
Outlet water temperature has exceeded the
maximum outlet water temperature.
• Verify that the system is full of water and that all air
has been properly purged from the system.
• Verify that the boiler is piped properly into the heating
system. Refer to Section 6 - Hydronic Piping of the
SYNC Installation and Operation Manual
for the proper piping methods for the SYNC boiler.
• Check for voltage to the boiler pump motor on a call
for heat. If voltage is not present, check wiring back
to the pump relay. Replace the pump relay if
necessary.
• If 120 VAC is present on a call for heat and the boiler
pump is not operating, replace the pump.
Service Manual
