Linksys EtherFast FENSK05 v2 - Manual (Page 18)

10/100 Network In a Box
31
Linksys EtherFast ® Series
30
3. Click on the Select from list... button to select a network adapter.
4. Click on the Have Disk button. Insert the EtherFast 10/100 LAN Card
Driver Disk into drive A. Type a:\ into the box on your screen and hit
OK.
5. Highlight the Linksys LNE100TX Fast Ethernet Adapter (LNE100TX
v4) entry in the window that appears. Click OK.
Windows NT 4.0 Installation &
Setup
Overview
The following instructions will set up the EtherFast 10/100 LAN Card in a
computer running NT 4.0 server/workstation. You should have your original
Windows NT CD-ROM handy during the installation, as you might be asked
to supply it. Always contact your network administrator or consult your NT
documentation if you have questions.
To install the network driver for an NT 4.0 Server or Workstation
1. Log into Windows NT as an administrator.
2. Click on Start, Settings, Control Panel, and then double-click on the
Network icon.
3. If you have not previously installed Windows NT networking on your
computer, a message will appear that reads: Windows NT Networking is
not installed. Do you want to install it now?
• If you see this message, click Yes to install NT networking along with the
EtherFast Card's network driver, and continue with step 1 below.
• If you don't see this message, NT networking is already installed. Skip to
step 1 on page 36.
Installing NT Networking & the EtherFast Card Driver
1. After clicking on Yes, the Network Setup Wizard window will appear.
2. Put a checkmark next to the Wired to the network option. Click Next.
