Diagnostic information 2-53
5021-0XX
914—Laser fan service check
Step Questions / actions Yes No
1 Turn printer off and remove
I/O board shield. See
“I/O
board removal” on
page 4-70
for steps to
remove I/O board shield. Is
cable properly connected
to I/O board connector
DCN8?
Go to step 2. Properly connect
cable.
2 Ensure rear cover
assembly cover is shut.
Override top and front
cover interlock switches.
For location, see
“Interlock switch
locations” on page 5-8
.
Reconnect operator panel.
Turn printer on and check
for 24VDC between DCN8
pin 1 and power ground
(you can touch negative
lead of voltmeter to metal
bracket that holds I/O
board to obtain ground.) Is
voltage present and
correct?
Replace laser
unit fan
assembly. See
“Laser unit fan
assembly
removal” on
page 4-26
.
Retest printer. If
error clears,
problem solved,
otherwise go to
step 3.
Replace I/O
board. See
“I/O
board removal”
on page 4-70
.
Retest printer. If
error clears,
problem solved,
else go to step 3.
3 Turn printer off and check
cable that connects engine
controller board connector
I2CN to I/O board
connector DCN3 for
continuity and pin shorts. Is
cable okay? Replace engine
controller board.
See
“Engine
controller
board removal”
on page 4-55
.
Replace cable.
