E-2 TROUBLESHOOTING E-2
POWER FEED™ 25M
Observe all Safety Guidelines detailed throughout this manual
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
CAUTION
PROBLEMS
(SYMPTOMS)
POSSIBLE
CAUSE
RECOMMENDED
COURSE OF ACTION
Fault Code
Err 006
Err 100
Err 53 Voltage sense loss.
Err 81 Motor overload, long term.
Err 82 Motor overload, short term.
Err 95 Spool gun or pull gun motor
overload.
Err 263 No usable weld modes.
Description
1. The wire feeder has not received
a recognition command from the
power source.
1. The power source has issued a
shutdown command.
1. The wire drive motor has over-
heated.
1. The wire drive motor current draw
h a s e x c e e d e d l i m i t s , u s u a l l y
because the motor is in a locked
rotor state.
1. The drive motor in the spool gun
or push-pull gun is drawing too
much current.
1. The power source does not have
any welding programs loaded.
Possible Adjustments
1. Verify the power source is operat-
ing properly. (Status light steady
green.)
2. Check control cable for loose or
broken leads.
3. S e e p o w e r s o u r c e I n s t r u c t i o n
Manual.
1. Verify the power source is operat-
ing properly (Status light steady
green.)
2. Check control cable for loose or
broken leads.
3. S e e p o w e r s o u r c e I n s t r u c t i o n
Manual.
1. Check that the electrode slides
easily through the gun and cable.
2. Remove tight bends from the gun
and cable.
3. Check that the spindle brake is
not too tight.
4. Verify a high quality electrode is
being used.
5. Wait for the error to reset and the
motor to cool. (approximately 1
minute).
1. Check that motor can turn freely
when idle arm is open.
2. Verify that the gears are free of
debris and dirt.
1. Check that the wire moves freely
through the gun when the gun is
straight.
2. Verify the correct size contact tip
is installed in the gun.
1. See the power source Instruction
M a n u a l f o r l o a d w e l d i n g p r o -
grams.
Linc-Net System Error Codes
ArcLink System Error Codes
