B-20 OPERATION B-20
POWER FEED™ 25M
GMAW-STT™ WELDING
Surface Tension Transfer, or STT™ welding, is a
break-through process offered exclusively by the
Lincoln Electric Company. STT™ is a low heat, low
spatter process created with Waveform Control
Technology™. STT™ is the process of choice for
open root welding, welding on thin materials or weld-
ing on parts with poor fit-up. Low spatter, even when
using 100% CO
2
shielding gas, results in cost sav-
ings in gas and part clean-up.
Several sets of STT™ weld modes are available.
• Modes 110 and 126 provide individual control of
peak current, background current and tail-out, and
are most often used in robotic applications.
• Modes 123 and 124 include Hot Start and give total
control of the arc.
• Synergic STT™ modes keep the arc characteristics
the same when the wire feed speed is changed.
Note: STT™ is available only with specially equipped
Power Wave power sources, like the Power Wave
455M/STT.
For best results:
• Attach the work sense lead as close as possible to
the welding arc.
• Use only solid steel, stainless steel or silicon
bronze electrodes.
1 K2203-1 Power Wave 455M/STT
K2230-1 POWER FEED™ 10M, Bench Model
K2234-1 POWER FEED™ 10M Dual, Bench Model
2 K2536-1,-2,-3 POWER FEED™ 25M
KP1695-xx, Drive Roll Kit, 2 Roll Feeder
KP1507-xx Drive Roll Kit, 4 Roll Feeder
3 K1543-xx Digital Control Cable
K2683-xx
4 K1796-xx, K2593-xx Coaxial Weld Power Cable, Lug to Lug
5 K910-xx Ground Clamp
6 K940-xx Sense Lead Kit
7 See Magnum ® MIG Gun
Literature
Deluxe Regulator for Mixed
8 K586-1 Shielding Gases
Shielding Gas Hose
8
4
3
2
7
1
5
6
FIGURE B.15
