B-40
OPERATION
B-40
POWER FEED™ 25M
INTERNAL CONTROLS
(FOR CODE 11456 and higher)
1
Cold Feed / Purge Switch
2
Wire Drive Pressure Arm
3
Internal Light Switch
4
Internal Heater Switch
5
Spindle Brake
6
Gun Bushing
ITEM
DESCRIPTION
1
8
7
6
3
2
7
Thumb Screw for securing the welding Gun
8
Socket Head Cap Screw for securing the Gun Bushing
4
5
