Lanier CW2200SP - Manual (Page 174)

3. Press [Adjust Print Position].
4. Select the paper input location of the print position you want to adjust, and then press
[Print Test Sheet].
5. Press [Start Printing].
6. Check the optimal adjustment value based on the print results of the test sheet.
• Measure the margins between the center of the printed lines and the paper edges.
CQA006
• Adjust so that the margins are 5 mm (0.20 inches). For example, if the center of the horizontal
line is printed 4 mm (0.16 inches) from the top edge of the sheet, the adjustment value of "Top
Margin" is "1.0 mm (0.04 inches)".
• In the same manner, if the center of the vertical line is printed 8 mm (0.32 inches) from the left
edge of the sheet, the adjustment value of "Left Margin" is "-3.0 mm (-0.12 inches)".
9. Troubleshooting
172
