Item
# 6062 FRUs FRU# CRU Tier
10 Microprocessor, Pentium Dual Core E5200 WOLFDALE 2.5GHZ 800FSB 2M 65W
M0 Stepping (models)
46R9512 N
10 Microprocessor, Q9400 Yorkfield 2.66GHZ 1333MHZ FSB 6MB 4/4 L2 95W R0
stepping (models)
46R8644 N
11 System board - Jupiter AMT(GA) fixed ODD issue; support 45nm processor (hard
from 43C2298) (models)
45R5316 N
11 System board - Jupiter AMT(GA) fixed ODD issue; support 45nm processor
(models)
46R8690 N
11 System board - Jupiter non AMT(GA) fixed ODD issue ; support 45nm processor
(Hard from 87H5131) (models A2M A2A A2T A2K A2J A3J A4J A5J A6J A7J A1M
A1A A1T A1Q A1K A1J A8J A9J AAJ ABJ ACJ ADJ AEJ AFJ)
45R5315 N
11 System board- Jupiter non AMT(GA) fixed ODD issue ; support 45nm processor
(models A2M A2A A2T A2K A2J A3J A4J A5J A6J A7J A1M A1A A1T A1Q A1K
A1J A8J A9J AAJ ABJ ACJ ADJ AEJ AFJ)
46R8689 N
12 Memory module, 1 GB PC2-5300 (667MHz) DDR2 SDRAM (models A2M A2A
A2T A2K A2J A3J A4J A5J A6J A7J A1M A1A A1T A1Q A1K A1J A8J A9J AAJ ABJ
ACJ ADJ AEJ AFJ)
41X4256 1
The FRUs listed in the following table are not illustrated.
6062 FRUs FRU# CRU Tier
Cable, SATA hard disk drive and optical drive (all models) 39K5061 2
FRU, Speaker/Cable Asm (all models) 39K5012 2
Under-desk Mounting Kit (all models) 39M0599 1
Bezel, Ultra-Bay-Enhanced (all models) 89P6804 2
HDD Tray Asm (includes grommet/pins/bracket/ground springs) (all models) 89P6778 2
Power/LED cable assembly with bracket (all models) 39K5055 2
Miscellaneous hardware kit (all models) 89P6794 2
Battery 3.0V (all models) 33F8354 1
Thermal Sense cable (850 mm) (all models) 41R2511 2
Front fan assembly (850 mm) (all models) 41R6359 2
SATA (450mm) / PATA(455mm) cable (all models) 43N9059 2
Fansink for Lagavulin III - Value FMB Copper with screened grease (all models) 41A7711 N
Ultra Bay Enhanced Bezel-Foxconn (all models) 43N9481 2
HDD Tray Asm (includes grommet/pins/brkt/gnd springs)-Foxconn (all models) 43N9482 2
Power/LED Cable Asm, with brkt-Foxconn (all models) 43N9483 2
Lagavulin/Apollo Chassis and Cover Asm-Foxconn (all models) 43N9485 N
Lag/Apollo Front Rotating Cage Asm ,Foxconn (all models) 43N9543 N
Top Cover-Foxconn (all models) 43N9486 N
Lag/Arm Fron Bezel Asm-Foxconn (all models) 43N9487 2
Lag/ApolloFron Bezel Asm-Foxconn (all models) 43N9488 2
FRONT FAN ASSY FOR Arm,Apollo-Foxconn (all models) 43N9489 2
Rear Exhaust Fan Asm ,Foxconn (all models) 43N9549 2
Vertical Stand-Foxconn (all models) 43N9490 1
Chapter 10. FRU lists 163
