Linksys PCMPC100 v3 - Manual (Page 25)

Instant EtherFast ® Series
44
EtherFast ® 10/100 PC Cards
45
If you are installing the EtherFast 10/100 PC Card in a Windows 95 or 98 PC
that you plan on logging into a NT domain server, follow the directions
below.
1. Follow the Windows 95 setup instructions or the Windows 98 setup
instructions
2. Start up Windows. Click on Start, Settings, then Control Panel. Double-
click on Network. The Network window appears. Click on the
Configuration tab.
3. In the Primary Network Logon box, choose Client for Microsoft
Networks, which instructs your PC to log into an NT 4.0 server where you
already have a username and password set up.
4. Under the the following network components are installed box, highlight
Client for Microsoft Networks and click on the Properties button.
5. The Client for Microsoft Networks Properties window will appear. Under
the Logon Validation box, make sure that Log on to Windows NT domain
is checked. Enter the name of your domain into the Windows NT Domain
box. Click OK.
6. Optional: Click on the Access Control tab. Make sure that Share-level
access control is selected; do not choose User-level access control. If
Access Control is grayed out and cannot be selected, refer to the
Troubleshooting section.
7. When you’re done, click OK. When asked if you want to restart your PC,
choose to do so.
The NT portion of the Windows setup is complete.
Windows 98 or 95 Client for windows NT
The instructions below explain how to set up the regular Novell NetWare 3.x
client for use on a Windows 98 or 95 PC.
1. Follow the Windows 95 setup instructions or the Windows 98 setup
instructions.
2. Start up Windows 95 or 98. Click on Start, Settings, then Control Panel.
Double-click on Network. The Network window appears. Click on the
Configuration tab.
3. Make sure that Client for Microsoft Networks and Client for Netware
Networks are listed. If either are missing, you will have to install them
manually. Refer to Manually Installing Network Components in Windows
98 and 95 in the Windows 98 Installation section.
4. In the Primary Network Logon box, choose Client for NetWare Networks.
5. Under the The following network components are installed box, highlight
Client for NetWare Networks and click on the Properties button.
6. The Client for NetWare Networks Properties window appears. Under the
General tab, enter the name of your network’s Preferred Server. Assign the
First Network Drive Letter; the default is F. If available, make sure the
Enable logon script processing is checked. Click OK.
7. Click on the Access Control tab. Make sure the Share-level access control
option is selected; do not select User-level access control.
8. When you’re done, click OK to restart your computer.
The NetWare portion of your Windows setup is complete.
Novell NetWare 3.x Client Setup for windows 98 or 95
