156
Service Manual
4039-1XX
Asm-
Index
Part
Number
Units
Description
12-1
1381082
1
Fuser and Lamp 110V 10R
-1
1381083
1
Fuser and Lamp 110V 12R/12L
-1
1381521
1
Fuser and Lamp 110V 12C
-1
1381084
1
Fuser and Lamp 220V 10R
-1
1381085
1
Fuser and Lamp 220V 12R/12L
-1
1381522
1
Fuser and Lamp 220V 12C
-1
1381010
1
Fuser and Lamp 110V 16L
-1
1381038
1
Fuser and Lamp 220V 16L
-1
1381626
1
Fuser and Lamp 110V 10P
-1
1381627
1
Fuser and Lamp 220V 10P
-1
1381679
1
Fuser and Lamp, Low Pressure 110V 10R
-1
1381678
1
Fuser and Lamp, Low Pressure 220V 10R
-2
1383314
1
Screw, Fuser Asm, Parts Packet
-3
1380785
1
Fuser Wiper Assembly (supply item) 10R/12R/
12C/12L/16L
-3
1382287
1
Fuser Wiper Assembly (supply item) 10P
-4
1039315
1
Fuser Cover 10R/10P
-4
1328132
1
Fuser Cover 12R/12L/12C/16L
-6
1038717
1
Spring Redrive Exit
-7
1383314
1
Screw, Parts Packet
-8
1383311
1
Fuser Lamp 110V 10R/12R/12L. Install lamp
with color-coded end away from gear.
-8
1381523
1
Fuser Lamp 110V 12C/10P. Install lamp with
color-coded end away from gear.
-8
1383324
1
Fuser Lamp 220V 10R/12R/12L. Install lamp
with color-coded end away from gear.
-8
1381524
1
Fuser Lamp 220V 12C/10P. Install lamp with
color-coded end away from gear.
-8
1381011
1
Fuser Lamp 110V 16L. Install lamp with color-
coded end away from gear.
-8
1381037
1
Fuser Lamp 220V 16L. Install lamp with color-
coded end away from gear.
