Service Manual
4039-1XX
Asm-
Index
Part
Number
Units
Description
3-1
1325196
1
Cover Hinge Asm 10R/12R/12C/10P (does not
include the load box)
-1
1381045
1
Cover Hinge Asm 12L/16L (does not include
the load box)
-1A
1383314
1
Screw, Cover Hinge Parts Packet
-2
1325103
1
Upper Plate Asm 10R/12R/12C/10P
-2
1328218
1
Upper Plate Asm 12L/16L
-3
1328215
1
Cartridge Load Box 10R/12R/12C/12L/16L
-3
1402284
1
Cartridge Load Box, 10P
-4
1383315
1
Right Cam Button, Parts Packet
-5
1039693
1
Right Bellcrank
-6
1383315
1
Left Cam Button, Parts Packet
-7
1328220
1
Spring, Bellcrank
-8
1039692
1
Left Bellcrank
-9
1383998
1
Fan Asm
NS
1424481
1
Pad, Acoustic (Fan)
-10
1328222
1
Plenum Asm 12R/12L/12C/16L
-10
1325022
1
Plenum Asm 10R/10P
-11
1383315
1
Retainer, Parts Packet
-12
1383316
1
Spring, Parts Packet
NS
1383315
1
Retainer, Parts Packet
-14
1383314
1
Screw, Parts Packet
NS
1383314
1
Washer, Parts Packet
-16
1383314
1
Screw, Plenum Mtg., Parts Packet
-17
1328307
1
Grip, Handle
-18
1325049
1
Handle Latch 10R/12R/12C/10P
-18
1328217
1
Handle Latch 12L/16L
-19
1328308
1
Sleeve
-20
1325108
1
Spring, Handle
-21
1383313
2
Ground Strap, Parts Packet
-22
1381004
1
Output Bin Sensor Assembly (handle
mounted) 12L/16L
-23
1383316
1
Retainer, E-Clip, Parts Packet
-24
1383315
1
Pivot, Handle--Parts Packet
-25
1383314
2
Screw, Parts Packet
