142 Service Manual
4039-1XX
Asm-
Index Part
Number
Units Description
5-27 1328452 1 Deflector, Paper 10R/12R/12C/12L/16L/10P
NS 1328450 1 Spring, Shaft Grd. 12L/16L
-28 1381617 1 Kit, Anti-Squeak Bearing 10P/10R/12R/12C
-28 1381618 1 Kit, Anti-Squeak Bearing 12L/16L
-29 1328381 1 Outer Redrive Shield 12L/16L
NS 1383314 1 Screw Backup Spring Mtg., Parts Packet
-30 1183245 1 Spring, Arm Tray Bias
-31 1383314 1 Screw, Redrive Mtg., Parts Packet
-33 1328298 1 Guide, Fuser Input
-34 1328167 1 Redrive Assembly 12L/16L,With Handle-
Mounted Bin Sensor
-34 1381527 1 Redrive Assembly 12L/16L,With Redrive-
Mounted Bin Sensor
-34 1042230 1 Redrive Assembly 10R/10P
-34 1325515 1 Redrive Assembly 12R/12C
-35 1383314 1 Screw Parts Packet
NS 1328345 1 Spring, Bias, Transfer Housing
-36 1381298 1 Output Bin Sensor 12L/16L, redrive mounted
sensor
-37 1376284 1 Cable, Output Bin/Op Panel 12L/16L, redrive
mounted sensor
-38 1381567 1 Kit, Bail, Minibail, and Guide 12L/16L, redrive
mounted sensor
