background image

138

Service Manual

4039-1XX

Asm-
Index

Part
Number

Units

Description

4-1

1381624

1

Printhead 10P

-1

1381005

1

Printhead 10R/12R/12C/12L/16L

-2

1328431

1

Printhead Shroud Assembly

-3

1325017

1

Cable, Fan/Mirror Motor

-4

1325018

1

Cable, hsync/Laser

NS

1038199

1

Cable, Tie

-6

1383315

1

Pin, Parts Packet

-7

1383316

1

Spring, Parts Packet

-8

1383314

2

Screw, Printhead Mtg., Parts Packet

-8A

1383314

1

Screw, Hex Headed Parts Packet

-8B

1383314

1

Pointer, Parts Packet

-9

1383315

1

Retainer, Parts Packet
