System and Control Options
80
9.11 Manual Output Ctrl
The Manual Output Ctrl feature allows you to manually change the state of any digital output to ON
or OFF, overriding automatic control by the Universal Monitor (the default setting for all outputs).
This menu also allows you to release the manual override, returning any output to automatic control.
There are two ways to override automatic control of outputs:
• Use the Manual Output Ctrl menu, as described in this section, to turn any output ON or OFF.
• Use the switch on the Universal Monitor board (see 1.7 - Controller Board Overview) to force
all eight outputs ON at the same time. (Note: This has no effect on the optional Expansion Board
outputs.)
After an output is forced manually ON or OFF through the Manual Output Ctrl menu, it remains in
that state until returned to automatic control through this menu.
Table 34 summarizes the four types of control, including the abbreviated message that appears on
the LCD and in log reports.
To force an output point ON or OFF or return it to automatic control:
Log In and Choose Manual Output Ctrl
• From the Main Menu, use the arrows ↑ ↓ to choose System and
Control, then press Enter ↵ (see 9.1 - Login for help).
• Enter your password at the Login screen.
• From the System and Control Menu, use the arrows
↑ ↓ to choose
Manual Output Ctrl, then press Enter ↵ .
Select an Output
The Select Output menu, shown at right, display the current status
of all eight outputs.
• Use the arrows ↑ ↓ to choose the output you want—for example,
Output01—and press Enter ↵ .
Turn Output ON or OFF / Return to Automatic
• From the Override Output menu, use the arrows ↑ ↓ to choose
one of these options:
• Auto (return to automatic control)
• Man ON (manually turn this output ON)
• Man OFF (manually turn this output OFF)
• Press Enter ↵ .
Table 34 Automatic / manual control - output points
Message Description
AUTO Automatic Controlled by Universal Monitor
MAN ON Manually ON
This output forced ON or OFF
via Manual Output Ctrl menu
MAN OFF Manually OFF
HW MAN ON
Manually ON
(all outputs)
All outputs forced ON
via hardware switch on circuit board
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑ ↓=NEXT ↵
=SELECT
Login
LOGIN
AAAA
↑ ↓=SELECT ↵
=NEXT/END
System & Control Menu
SETUP SYSTEM
> MANUAL OUTPUT CTRL
CLEAR ALARMS & LOGS
↑ ↓=NEXT ↵
=SELECT
Select Output
OVERRIDE OUTPUT
> OUTPUT01 AUTO
OUTPUT02 AUTO
↑ ↓=NEXT ↵
=SELECT
OUTPUT03 AUTO
OUTPUT04 MAN ON
OUTPUT05 AUTO
OUTPUT06 AUTO
OUTPUT07 MAN OFF
OUTPUT08 AUTO
OUTPUT09 AUTO
OUTPUT10 MAN ON
OUTPUT11 AUTO
OUTPUT12 AUTO
OUTPUT13 MAN OFF
OUTPUT14 AUTO
OUTPUT15 AUTO
OUTPUT16 AUTO
Override Output
SELECT OUTPUT01
AUTO
↑ ↓=SELECT ↵
=END
NOTE: OUTPUT09-OUTPUT16
for optional Expansion Board
