View Status Menus
97
A.4.5 View Input Status
For details on this feature, see 7.5 - View Input Status.
View Input & Sensor Status
INPUT & SENSOR STATUS
Sensor values & discrete inputs status
INPUT STATUS/VALUE
SENSOR_1 80.0 DEG
SENSOR_2 ------ DEG
SENSOR_3 80.0 DEG
SENSOR_4 79.5 RH
INPUT_01 NORMAL
INPUT_02 ALARM
INPUT_03 EVENT
INPUT_04 ALARM
INPUT_05 ALARM
INPUT_06 EVENT
INPUT_07 NORMAL
INPUT_08 NORMAL
INPUT_09
EVENT
INPUT_10 NORMAL
INPUT_11 NORMAL
=MORE =EXIT =ALL
INPUT_12 NORMAL
INPUT_13 ALARM
INPUT_14 EVENT
INPUT_15 ALARM
INPUT_16 ALARM
INPUT_17 EVENT
INPUT_18 NORMAL
INPUT_19 NORMAL
INPUT_20 EVENT
INPUT_21 NORMAL
INPUT_22 NORMAL
INPUT_23 NORMAL
INPUT_24 NORMAL
1=VIEW SENSOR_1 DYNAMICALLY
2=VIEW SENSOR_2 DYNAMICALLY
3=VIEW SENSOR_3 DYNAMICALLY
4=VIEW SENSOR_4 DYNAMICALLY
5=REFRESH INPUT & SENSOR STATUS
6=RETURN TO MAIN MENU
SELECT A NUMBER:1
VIEWING SENSOR_1 DYNAMICALLY
SENSOR_1 80.0 DEG
PRESS KEY TO EXIT
