System and Control Options
44
Figure 14 shows the main options available from the System & Control menu.
Figure 14 Menu overview - System and Control menu
Opening Screen
UNIVERSAL MONITOR
DD-MON-YY HR:MM:SS
VX.XXX.X
PRESS
↵
=STATUS/SETUP
Main Menu
VIEW STATUS
> SYSTEM AND CONTROL
↑ ↓ =NEXT
↵
=SELECT
Login Screen
LOGIN
AAAA
↑ ↓ =SELECT
↵
=NEXT/END
System & Control menu
Setup System selected
System & Control menu
Manual Output Ctrl selected
System & Control menu
Clear Alarms&Logs selected
> SETUP SYSTEM
MANUAL OUTPUT CTRL
CLEAR ALARMS & LOGS
SETUP SYSTEM
> MANUAL OUTPUT CTRL
CLEAR ALARMS & LOGS
SETUP SYSTEM
MANUAL OUTPUT CTRL
> CLEAR ALARMS & LOGS
Setup System menu Select Output Clear Alarms/Logs menu
SETUP INPUT
SETUP COMMON ALARM
SETUP SENSOR
SETUP I/O MATRIX
SETUP OUTPUT
SETUP MODEM&PAGERS
SETUP SYSTEM INFO
SETUP EXP BOARD
See
Section
9.2
OVERRIDE OUTPUT
> OUTPUT01 AUTO
OUTPUT02 AUTO
.
.
.
OUTPUT16 AUTO
See
Section
9.11
CLEAR ACTIVE ALARMS
CLEAR ALARM LOG
CLEAR EVENT LOG
CLEAR TREND LOGS
See
Section
9.12
Override Output
SELECT OUTPUT01
AUTO
CLEAR ACTIVE ALARMS
ARE YOU SURE? N CLEAR ALARM LOG
ARE YOU SURE? N
CLEAR EVENT LOG
ARE YOU SURE? N CLEAR TREND LOGS
ARE YOU SURE? N
Setup Input Setup Common Alarm Setup Sensor Setup I/O Matrix
SELECT INPUT
> INPUT_01 NO-AL-NL
INPUT_02 NO-AL-NL
.
.
.
INPUT_24 NO-AL-NL
See
Section
9.3
RESET COMMON ALARM
WITH SILENCE? N
See
Section
9.4
SELECT SENSOR
> SENSOR_1 +80.00 DEG
.
.
.
SENSOR_4 +79.50 RH
See
Section
9.5
MAP INPUT TO OUTPUT
MAP SENSOR TO OUTPT
See
Section
9.6
SETUP INPUT_01
LABEL: INPUT_01
NORM OPEN/CLOSE: NO
ALARM/EVENT: AL
LATCHED: N
DELAY: 00:01
SETUP SENSOR_1
CONNECTED : N
LABEL: SENSOR_1
UNITS: ___
4 mA: -999.9
20 mA: +999.9
OFFSET: +000.0
ALARM/EVENT: AL
LATCHED: N
LOW SETPT: -950.0
HIGH SETPT: +950.0
SENSOR DELAY: 00:01
Setup Output Setup Modem & Pagers
SELECT OUTPUT
> OUTPUT01 NO
OUTPUT02 NO
.
.
.
OUTPUT16 NO
See
Section
9.7
SETUP PAGERS
SETUP MODEM
See
Section
9.8
Setup System Info Setup Exp Board
CHANGE PASSWORD
CHANGE DATE & TIME
SETUP SITE ID
CONNECT BATTERY
SETUP SERV PH NUM
FACTORY DEFAULTS
See
Section
9.9
IS THE EXPANSION
BOARD CONNECTED? N
↑ ↓=Y/N
↵
=END
See
Section
9.10
CHANGE LABEL
CHANGE STATE SELECT PAGER
PAGER NUMBER 1
.
.
.
PAGER NUMBER 4
ENTER INIT STRING
ATS0=1
See Figure 15 for details
on Setup System Info
SET PAGER 1 NUMBER
SET PAGER 1 PIN
Setup System options
SELECT INPUT
INPUT_01
INPUT_02
.
.
.
INPUT_24
SELECT SENSOR
SENSOR_1 HIGH STPT
SENSOR_1 LOW
STPT
.
.
.
SENSOR_4 LOW STPT
SELECT OUTPUTS
MAP TO MAIN BOARD
MAP TO EXP BOARD
SELECT OUTPUTS
MAP TO MAIN BOARD
MAP TO EXP BOARD
1 OUTPUT MAP
1 2 3 4 5 6 7 8
Y N N N N N N N
1H OUTPUT MAP
1 2 3 4 5 6 7 8
Y N N N N N N N
or or
1 OUTPUT MAP
0910111213141516
N N N N N N N N
1H OUTPUT MAP
0910111213141516
N N N N N N N N
