Default Settings Quick Reference Guide
134
Table 39 Expansion Board - default settings for inputs and outputs
DEFAULT SETTINGS - DIGITAL INPUTS (FROM TABLE 21)
Feature Default Other Options
LABEL INPUT_09 - INPUT_24 Any name (up to eight characters)
NORM OPEN/CLOSE NO (Normally open) NC (Normally closed)
ALARM/EVENT AL (Alarmable) EV (Event)
LATCHED NL (Unlatched) / N (No)* L (Latched) / Y (Yes)*
DELAY 00:01 (1 second) Any time (in minutes and seconds) from 00:00 to 99:59
* NOTE: Different abbreviations are used to designate a digital input as Latched or Unlatched.
DEFAULT MAPPING OF DIGITAL INPUTS TO DIGITAL OUTPUTS (FROM TABLE 23)
Digital input By default, mapped to digital output:
Input_09 (none)
Input_10 (none)
Input_11 (none)
..
.
(none)
Input_24 (none)
NOTE: By default, no Expansion Board inputs are mapped to any outputs.
DEFAULT SETTINGS - DIGITAL OUTPUTS (FROM TABLE 25)
Feature Default Other Options
LABEL OUTPUT09 - OUTPUT16 Any name (up to eight characters)
Table 40 Expansion Board - other default settings
CONNECTION TO UNIVERSAL MONITOR (see 9.10 - Setup Exp Board - Optional Expansion Board)
Feature Default Other Options
SETUP EXP BOARD (IS THE
EXPANSION BOARD
CONNECTED?)
N (Not connected) Y (Connected)
DIP SWITCH SETTINGS
Feature Default Other Options
S1 Digital output DIP switches Off (NO - Normally Open) On (NC - Normally Closed)
OTHER SWITCH SETTINGS
Feature
Default
For all switches:
1 = ON, 0 = OFF
Other Options
SW1 (factory configured) 11111111 —
SW2 (factory configured) 11111111 —
SW3 (factory configured) 10000100 —
SW4 (factory configured) 10000100 —
JUMPER SETTINGS
Feature Default Other Options
JP2 (factory configured) Left two pins jumpered —
JP3 (factory configured) Left two pins jumpered —
JP4 (factory configured) Left two pins jumpered —
JP5 (factory configured) Bottom two pins jumpered —
