4: Configuration Using Web-Manager
UDS1100 User Guide 26
If this option is not selected, complete the fields that become
available:
‹ Speed: The speed of data transmission. The default
setting is 100 Mbps.
‹ Duplex: The direction of data transmission. The
default setting is Full.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Server Configuration
The unit’s server values display when you select Server from the main menu. The
following sections describe the configurable parameters on the Server Settings page.
Figure 4-4. Server Settings
To configure the UDS1100’s device server settings:
1. On the main menu, click Server.
2. Configure or modify the following fields:
Server Configuration
Telnet Password Enter the password required for Telnet access.
Retype Password Re-enter the password required for Telnet access.
Advanced
ARP Cache Timeout When the unit communicates with another device on the
