Technical specifications
Battery:
One Lithium-ion Battery NP-400
Optional power source:
AC adapter (AC-1L or AC-11)
Vertical Control Grip VC-7D
Battery performance (recording): Approx. number of recorded images: 400 frames.
Based on the CIPA standard with a NP-400 lithium-
ion battery, 512MB CompactFlash card.
Dimensions:
150.0 (W) X 106.0 (H) X 77.5 (D) mm
5.9 (W) X 4.2 (H) X 3.1 (D) in
Weight:
Approximately 760g (26.8 oz)
(without batteries or memory card)
Operating temperature:
0° - 40°C (32° - 104°F)
Lithium-ion Battery Charger BC-400
Input voltage:
AC 100-240V, 50-60Hz
Weight:
86g (3.0 oz.)
Dimensions:
65 (W) X 90 (H) X 30 (D) mm
2.56 (W) X 3.54 (H) X 1.18 (D) in
Lithium-ion Battery NP-400
Voltage:
7.4V, 1500mAh
Weight:
85g (3.0 oz.)
Dimensions:
56.0 (W) X 39.5 (H) X 21.0 (D) mm
2.20 (W) X 1.56 (H) X 0.83 (D) in
Specifications are based on the latest information available at the time of printing and are subject to change
without notice.
TECHNICAL SPECIFICATIONS
Number of effective pixels:
6.1 million
CCD:
23.5 X 15.7mm interline primary-color CCD with a
total of 6.3 million pixels
Camera sensitivity (ISO):
Auto, 100, 200, 400, 800, 1600, 3200 ISO equiva-
lents
Aspect ratio:
3:2
A/D conversion:
12 bit
Autofocusing system:
TTL phase-detection system with CCD line sensor.
AF sensitivity range:
Ev -1 ~ +18 (at ISO 100)
Meter:
14-segment honeycomb-pattern SPC
Metering range:
Ev ±0 ~ +20 (Spot: Ev +3 ~ +20) at ISO 100, ƒ/1.4.
Shutter:
Electronically-controlled, vertical-traverse, focal-
plane shutter
Flash guide number:
12 (in meters at ISO 100)
Flash sync.:
1/125s with Anti-Shake, 1/160s without Anti-Shake
Flash coverage:
Equal to a 24mm focal-length lens
Built-in flash recycling time:
3s (approx.)
Viewfinder:
Eye-level fixed glass pentaprism.
Field of view:
95% (approx.)
Eye relief:
Approximately 25mm from the eyepiece or 21mm
from the eyepiece cup at -1 diopter.
Viewfinder magnification:
0.9x (50mm lens at infinity at -1 diopter).
Monitor LCD:
2.5 inch TFT color
Recording media:
Type I and II CompactFlash cards, Microdrives.
File formats:
JPEG and RAW.
DCF 2.0, DPOF, and Exif 2.21 compliant.
PRINT Image Matching III:
Yes
Menu languages:
English, German, French, Spanish, Japanese, Italian,
Swedish, and Chinese.
Video output:
NTSC and PAL
