Kodak 2500 - Manual (Page 19)

A-63055 December 1999 13
Specifying an Area To capture a portion of an image, click on the Area button to access
the Set Scanning Area dialog box. Area settings are determined by the
X and Y positions and the width and length coordinates.
Original Scanned image
Set the scanning area in the Set Scanning Area dialog box on the
basis of the size specified in the
Page Size drop-down list box. You
can also use the mouse to define the scanning area in the window.
• Units—select mm, inches, or pixels.
• X Position—the position from the left end of the document to the
left end of the scanning area.
•
Y Position—the position from the top end of the document to the
top end of the scanning area.
•
Width—the width of the scanning area.
• Length—the length of the scanning area.
