MIDI Implementation Chart
Basic
Channel Default
Changed
Aftertouch
Pitch Bend
Polyphonic (Key)
Monophonic (Channel)
Program
Change
Variable Range
System
Real Time Clock
Command
System Exclusive
System
Common
Song Position
Song Select
Tune
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO : Yes
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO No
Aux
Messages
Local On/Off
All Notes Off
Active Sense
Reset
Velocity Note On
Note Off
Note
Number:
True Voice
Mode Memorized
Messages
Altered
Memorized
Sequencer and Arpeggiator data
can transmit all note numbers 0–127
Polyphonic aftertouch transmitted *A
only as sequence data *A
When cue list is selected, corresponds to cue list *1
When cue list is selected, corresponds to cue lists 0–19 *1
*1
*1
Notes
*P, *A, *C, *E: Transmitted/received when Global P1: MIDI Filter (Program Change, After Touch, Control Change, Exclusive) is Enable, respectively.
*1: When Global mode P1: MIDI Clock is Internal, transmitted but not received. The opposite for External MIDI or PCI/F.
*2: LSB,MSB=02,00: Arpeggiator ON/OFF, 0A,00: Arpeggiator Gate control, 0B,00: Arpeggiator Velocity control
*3: LSB,MSB=00,00: Pitch bend range, 01,00: Fine tune, 02,00: Coarse tune
*4: In addition to Korg exclusive messages, Inquiry, GM System On, Master Volume, Master Balance, Master Fine Tune,
and Master Coarse Tune are supported.
Bank Select (MSB, LSB) *P
Joystick (+Y, –Y), Ribbon, Slider *C
Pedal, Portamento Time, Volume, IFX pan, Pan *C
Expression, Effect Control 1/2
*C
Damper, Portamento Sw., Sostenuto, Soft *C
Sound (Realtime Controls 1–4A: 74, 71, 79, 72) *C
Switch 1, 2, Foot Switch, Controller *C
Send 1, 2, Effect ON/OFF (IFXs, MFX1, MFX2)
*C
Data Entry (MSB, LSB) *C
Data Increment, Decrement *C
NRPN (LSB, MSB) *C, *2
RPN (LSB, MSB) *C, *3
Realtime Controls knobs 1–4 B-assign *C
Sequencer data (receive *C)
All Sound Off, Reset All Controllers *C
Control
Change
0, 32
1, 2, 16, 18
4, 5, 7, 8, 10
11, 12, 13
64, 65, 66, 67
70 – 79
80, 81, 82, 83
93, 91, 92, 94, 95
6, 38
96, 97
98, 99
100, 101
0 – 95
0 – 101
120, 121
Function Transmitted Recognized Remarks
*C
*P
*E*4
Consult your local Korg distributor for more information on MIDI IMPLEMENTATION.
