Kenwood G-EQ300 - Manual (Page 25)

G-EQ300 (En/K)
2 5
[Audio block]
Total harmonic distortion (at 1 kHz, Flat) ................. 0.005%
Frequency response ........................... 10 Hz ~ 70 kHz,
±
3 dB
Signal to noise ratio (IHF '66) ...................................... 108 dB
Graphic equalizer characteristics
Adjustment center frequencies ....... 40 Hz, 63 Hz, 98 Hz,
160 Hz, 250 Hz, 400 Hz, 625 Hz, 1 kHz, 1.5 kHz, 2.5 kHz, 3.9
kHz, 6.3 kHz, 10 kHz, 16 kHz
Equalizer characteristic variable range ...............
±
12 dB
Input impedance
Line ............................................................................. 47 k
Ω
Maximum output voltage (at 1% T.H.D.) ......................... 7 V
Output Impedance
Line ............................................................................ 2.2 k
Ω
Specifications
Notes Notes
1. KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
2. The full performance may not be exhibited in an extremely cold location (under a water-freezing temperature).
3
Caution : Read this page carefully to ensure safe operation.
[General]
3
AC outlets
For the U.S.A. and Canada
UNSWITCHED .................................... 1 (200W, 1.6A max.)
For other countries
UNSWITCHED .............................................. 1 (200W max.)
Power consumption ........................................................ 18 W
Dimensions .......................................... W : 400 mm (15-3/4“)
H : 141 mm (5-9/16“)
D : 385 mm(15-3/16“)
Weight (net) ...................................................... 4.6 kg (10.2 lb)
