6
Mo
ving Around
What’s on Remote Control Unit?
1. Playback/recording mode indicators
` Play indicator/ 8: Pause indicator/
REC REC
: Record indicator/
7: Stop indicator
2. Character display
Shows various information such as the input device name and track
number.
3. Current function of LCD function button 1
4. Current function of LCD function button 2
5. Communication indicators
: Sending. : Receiving.
6. Battery indicator
“ ” appears when the batteries are nearly exhausted. In this case,
replace all of the four batteries together.
To switch the menu:
The menu can be switched over or selected while LCD function button 1
and/or 2 are displayed.
(Examples: Home, Back, Menu, Enter, etc.)
LCD function
button 1 LCD function
button 2
LCD Indicators
Cursor up/down
buttons
2WAY LCD REMOTE CONTROL UNIT
CD1:
CD
Disc 001 Tr.01
Text Menu
REC REC 1
2
3 4
5
6
