8 EXPANSIVE APPLICATION SOFTWARE

58

CONTENTS

TS-590S

ARCP-590 is capable of visually showing the location of the current RX frequency on the display and
of shifting the current RX frequency to the center of the scan span. The scan center frequency and
the scan span can be stored for each amateur radio band. It is ideal for checking the condition of
respective bands for specified frequency ranges.

Figure 8-6 Visual Scan

Note: During the scan, the receive audio of the transceiver is muted.

In ARCP-590, the setting of the audio filter can be configured with a graphic equalizer-type interface.
ARCP-590 has 18 bands from 0 Hz through 5,100 kHz.

Figure 8-7 Audio Equalizer

8.3.4 Visual Scan

8.3.5 Audio Equalizer
