1 RECEPTION

TS-590S

CONTENTS

7

Measurement Conditions:

The abscissa axis shows the distance from the interfering signal. For example, it represents that at
the point of 10 kHz the receive frequency is 14.200 MHz and two interfering signals of 14.210 MHz
and 14.220 MHz are given.
The orange line shows the result of TS-590S and the gray line shows the result of TS-480S.
In the event the frequency separation is greater than 20 kHz, the dynamic ranges of both transceivers
exceed 105 dB; however, as the separation becomes smaller (the interfering signals come closer to
the receive frequency), the dynamic range of TS-480S with conventional MCFs is decreasing. As the
graph of pass bandwidth shows, this results due to the difference of attenuation at the roofing filter.

Note: In the receive frequency and its adjacent band, the measurement at the level of “3 dB higher than the ordinary noise level”

may not be feasible due to influence of the noise generated from its local oscillator. Instead, the level, which has been

reached to S5 with the measurement by an S-meter, is predetermined as the reference level, and the level is converted to

the same level as the predetermined level, namely “3 dB higher than the ordinary noise level”, and then appears on the

graph of pass bandwidth. For comparison, both transceivers were measured using the same measuring method. The

outcome is an example and does not warrant the performance of the product.

Receive

Frequency

14.200 MHz

Mode

CW

Pass bandwidth

500 Hz

PRE AMP

OFF
