Kodak i30 / i40 - Manual (Page 25)

22 A-61512 May 2006
6. Click OK on the Kodak Scanner Properties dialog box. The Scan
Validation Tool screen will be displayed:
7. Place some test application documents into the input tray of the
scanner. The documents should be placed upside down in the input
tray. If you are scanning one-sided documents or if you have a
Kodak i30 Scanner, be sure the side you want to scan is facing the
input tray.
8. Click the Start button on the Scan Validation Tool. The documents
will be scanned and displayed in the Scan Validation Tool window.
NOTE: If the scanner is in lamp saver mode, a message will be
displayed that the lamps need sufficient time to warm up.
After the images have been displayed, your scanner installation
verification is completed.
9. Click the Close box to exit the Scan Validation Tool.
