A-61371 September 2004 2-5
Control Panel
1 Centering/Fit key — when pressed, enables or disables the
Centering and Fit functions. When Auto Masking, Trimming or
Masking are set to Off, Auto Masking will automatically be enabled
when Centering is selected.
2 Masking — when pressed, cycles through Off, Trimming, Masking
if the system has the optional Manual Masking Kit.
Centering Fit Masking Auto
Masking Auto Skew
Correction
Focus AF
1 5 6 2 3 4
Centering: centers all masked images onto the printed
page.
Fit: enlarges the displayed image to fill the page when
printed. Enlargement is only to the full length or width
of the paper, whichever is achieved first.
Off Indicates no masking or trimming will be done.
Masking: prints only the image outside of the area that
is defined on the screen.
Trimming: prints only the area of the image that is
defined on the screen.
• If Trimming is selected from the Off state, the
previously entered settings for Centering/Fit and
Manual Masking are applied.
• From Trimming, when Masking is selected, the
Centering/Fit setting is disabled and the previous
settings for the Masking area are applied.
• The Manual Masking area will be cancelled whenever
Off is selected from the Masking state.
• Trimming or Masking are not available through the
Auto Masking function.
