MC9000-K/S for Embedded Windows® CE .NET Product Reference Guide 7-10
Single Slot Serial/USB Cradle
This section describes how to set up and use a CRD 9000-1000S Single Slot Serial/USB Cradle with
the MC9000-K and MC9000-S. For cradle setup see
Figure 7-4 , for cradle communications setup
procedures see, Serial Communications Setup on page 4-10 .
Figure 7-4. Single Slot Serial/USB Cradle
Indicator
LED Bar
Mobile
Computer Slot
Spare
Battery
Spare
Battery
Charging
Well
Spare
Battery
Charging
LED
Power Port Serial Port USB Port
