QUICKIE 2 PAGE 53
UNILATERAL WHEEL LOCK
Pos. Item Number Description Remarks
1 230032 M6 x 16 B/H CAP SCREW
2 501032 CLAMP CAP
3 501031 WHEEL LOCK EXTENSION
4 230052 M6 1 x 10 BH C/S BLK
5 501033 REMOTE LOCK CLAMP
1-6A 882124 REMOTE LOCK ASSEMBLY RIGHT SHOWN
1-6B 882122 REMOTE LOCK ASSEMBLY LEFT
7 883300 1-HAND WHLLCK RLCMNT HNDL KIT
1,2,3,8A 882123 HAND LOCK ASSEMBLY RIGHT SHOWN
1,2,3,8B 882121 HAND LOCK ASSEMBLY LEFT
9 226112 1/4-28 x 1 SOC C/S BLK
10 262114 1/4 WASHER HI COLLAR
11 550632 EXTND CLAMP 2 1/4"NONRECSS BLK
12 550631 EXTND CLAMP 2 1/4"RECESS BLK
13A 341760 WHEEL LOCK CABLE SHORT (11"-14") 11 -14" WIDE CHAIRS
13B 341761 WHEEL LOCK CABLE MEDIUM (15"-18") 15 -18" WIDE CHAIRS
13C 341762 WHEEL LOCK CABLE LONG (19"-22") 19 -22" WIDE CHAIRS
9-12 880422 WHL LCK EXTND CLMP ASSM BLK
1-6A,8A-12,13A 902184 UNILTERAL 1HAND PSH LOCK SHT RH SHOWN 11 -14" WIDE
1-6A,8A-12,13B 902186 UNILTERAL 1HAND PSH LOCK MED RH SHOWN 15 -18" WIDE
1-6A,8A-12,13C 902188 UNILTERAL 1HAND PSH LOCK LONG RH SHOWN 19 -22" WIDE
1-5,6B,8B,9-12,13A 902183 UNILTERAL 1HAND PSH LOCK SHT LH 11 -14" WIDE
1-5,6B,8B,9-12,13B 902185 UNILTERAL 1HAND PSH LOCK MED LH 15 -18" WIDE
1-5,6B,8B,9-12,13C 902187 UNILTERAL 1HAND PSH LOCK LONG LH 19 -22" WIDE
