QUICKIE 2 PAGE 107
Pos. Item Number Description Remarks
21 500806 HEMI ELR ADJ STOP FRONT SMALL
22 481117 ELR LOCK ROD
23 561197 PLASTIC PIVOT SADDLE
24 561079 S/A LATCH LEVER
25 321136 S/A SPRING L RED
25 321137 S/A SPRING R CLEAR
28 560420 ELR UPPER PIVOT PLST
29 221100 1/4-28 X 3/4 HEX C/S
30 262110-QU 1/4 AN WASHER FLAT THIN
31 201112 1/4-28 NUT THIN
32 922324 HEMI ELR HNGR ASSM 14-15 W/PA
32 922325 HEMI ELR HNGR ASSM 16-17 W/PAD
32 922326 HEMI ELR HNGR ASSM 18-20 W/PAD
33 750226 KNEE PAD FLAT 3H X 5L W/COVER
34 922328 ELR HEMI KNEE PAD ASSM
26,27 881500 LATCH BLOCK ASSM R
26,27 881501 LATCH BLOCK ASSM L
13,14 882411 ELR 90D ACTUATION ARM ASSM
1-9,23-27 921826 ELR PIVOT BLOCK ASSM R
1-9,23-27 921827 ELR PIVOT BLOCK ASSM L
11,13-19, 21,22 922323 HEMI ELR LOCK ROD/ARM ASSM
1-31 921828 HEMI ELR HANGER W/O PAD R
1-31 921829 HEMI ELR HANGER W/O PAD L
