Sunrise Medical One-Arm Drive Quickie 2 - Manual (Page 39)

[04/2007]
QUICKIE 2 PAGE 39
MULTI-POSITION FORK W/PIN LOCK PLATE
Pos. Item Number Description Remarks
1 203100 1/2 - 20 NYLOCK NUT
2 264100 1/2 AN WASHER FLAT
3A 521560 3/4" CASTER STEM SPACER BLK
3B 521562 1 1/2" CASTER STEM SPACER BLK
4A 481712 CASTER STEM P1/P5
4B 481005 CASTER STEM + 3/4" PIN LOCK
4C 481007 CASTER STEM + 1-1/2" PIN LOCK
5 203110 1/2 - 20 JAM NUT
6 483254 SPACER .50 ID x .88 OD x .125
7 505012 CASTER PIN LOCK PLATE
8 264100 1/2" AN WASHER FLAT
9A 550644 MULTI-POSITION FORK TALL
9B 550646 MULTI-POSITION FORK SHORT
10 203100 1/2 - 20 NYLOCK NUT
11 222200 5/16 - 24 x 2 1/2 HEX C/S
12 202100-MJ 5/16 - 24 NYLOCK NUT THIN
13 481113 SPACET 5/16 x .380
4A, 6, 7, 8,9A-10 780242 MULTI-POSITION FORK TALL STD STEM PL RIGHT
4A, 6, 7, 8,9A-10 780243 MULTI-POSITION FORK TALL STD STEM PL LEFT
4B, 5, 7, 8,9A-10 780244 MULTI-POSITION FORK TALL 3/4 STEM PL RIGHT
