QUICKIE 2 PAGE 41
HIGH ANGLE CASTER PLATE
Pos. Item Number Description Remarks
1 201120 1/4 - 28 AUTOMATION NUT
2 561086 1" HALF SADDLE 1/4" HOLE
4 561070 CASTER CAP PLASTIC
4 920028 CASTER CAP PLASTIC PAIR
5 561004 1" SADDLE 1/4" HOLE
6 349500 1 1/8 x 1/2 BEARING
7 561050 ANTI-FLUTTER BUSHING USED W/ 8" CASTERS
8 262128 WASHER ECCENTRIC HD 1/4 HOLE
9A 225204 1/4 - 28 x 2 SOC HD C/S
9B 226257 1/4 - 28 x 2 1/4 SOC HD C/S USED W/ TRANSIT BRACKETS
10 262100-QU 1/4" AN WASHER FLAT
1, 2, 4, 5, 8-10 920474 CASTER PLATE HI ANGLE HARDWARE KIT
3, 6 780204 CASTER PLATE HI ANGLE DOUBLE BORING RIGHT
3, 6 780205 CASTER PLATE HI ANGLE DOUBLE BORING LEFT
3, 6, 7 780206 MULTI-POSITION FORK TALL STD STEM PL RIGHT
3, 6, 7 780207 MULTI-POSITION FORK TALL STD STEM PL LEFT
