PAGE 42 QUICKIE 2
CASTER PLATE
Pos. Item Number Description Remarks
1, 2 880554 CASTER CAP W/O RING ALUMINUM CLEAR ITEM 2 USED ON CHAIRS PRIOR TO 4/99
2 342006 CASTER CAP O-RING RUBBER ITEM 2 USED ON CHAIRS PRIOR TO 4/99
3 201120 1/4 - 28 AUTOMATION NUT
4 349034 SAFETY COTTER
5A 500306 INNER CLAMP HALF
5B 550762 CASTER CLAMP LXJ RECESS RIGHT
5C 550763 CASTER CLAMP LXJ RECESS LEFT
6A 500307 OUTER CLAMP HALF
6B 550760 CASTER CLAMP LXJ RIGHT
6C 550761 CASTER CLAMP LXJ LEFT
8 349500 1 1/8 x 1/2 BEARING
9 561070 CASTER CAP PLASTIC
9 920028 CASTER CAP PLASTIC PAIR
11 561050 ANTI-FLUTTER BUSHING USED WITH 8" CASTERS
12 481017 1/4 - 28 x 1.688 ECCENTRIC BOLT
13 349027 1/4 x 2 CLEVIS PIN
7, 8 780210 CASTER PLATE DOUBLE BEARING BLK RIGHT
7, 8 780212 CASTER PLATE DOUBLE BEARING BLK LEFT
7, 8 780208 CASTER PLATE DOUBLE BEARING CLEAR RIGHT
7, 8 780209 CASTER PLATE DOUBLE BEARING CLEAR LEFT
7, 8, 11 780200 CASTER PLATE SINGLE BEARING BLK RIGHT
7, 8, 11 780201 CASTER PLATE SINGLE BEARING BLK LEFT
3-9, 12, 13 780060 CASTER PLATE GP COMPLETE BLK RIGHT
3-9, 12, 13 780061 CASTER PLATE GP COMPLETE BLK LEFT
3-9, 12, 13 780040 CASTER PLATE GP COMPLETE CLEAR RIGHT
3-9, 12, 13 780041 CASTER PLATE GP COMPLETE CLEAR LEFT
