Sunrise Medical One-Arm Drive Quickie 2 - Manual (Page 28)

[04/2007]
PAGE 28 QUICKIE 2
HIGH ANGLE CASTER PIN LOCKS
Pos. Item Number Description Remarks
1 880761 PIN LOCK ARM W/ PIN S/A RIGHT
1 880762 PIN LOCK ARM W/ PIN S/A LEFT
2 500262 CASTER PIN LOCK BLOCK S/A BLK
3 321141 .650L x 6 COIL SPRING
4 262100-QU 1/4" AN WASHER FLAT
5 342000 1/4" E-CLIP
6 505667 PIN LOCK PLATE HI-ANGLE CASTER
7 226168 1/4 - 28 x .875 BH C/S
8 505666 PIN LOCK BLOCK HI-ANGLE CASTER
9 505012 CASTER PIN LOCK PLATE 1
1-5 880750 CASTER PIN LOCK S/A RIGHT
1-5 880751 CASTER PIN LOCK S/A LEFT
1-8 882700 HI-ANGLE CASTER PIN LOCK ASSM RIGHT
1-8 882701 HI-ANGLE CASTER PIN LOCK ASSM LEFT
